How to use Wireguard on NixOS with Gnome

A quick and simple guide to getting Wireguard running on NixOS when using the Gnome desktop environment (and NetworkManager).

Last updated for NixOS 25.05.

Requirements

• A functioning wireguard server that you are connecting to
• A NixOS device or virtual machine to act as the wireguard client

Steps

• Install wireguard tools and allow wireguard through the firewall via nix config

{ config, pkgs, ... }:

{
  environment.systemPackages = [
    pkgs.networkmanager
    pkgs.networkmanagerapplet # Adds nm-connection-editor
    pkgs.wireguard-tools # Allows using wg and wg-quick commands
  ];

  # Enable networking
  networking.networkmanager.enable = true;

  # Allow wireguard connections through firewall
  networking.firewall.checkReversePath = "loose";
}

You can either create this as a separate .nix file and import it with:

{
  imports = [
    ./path/to/file.nix
  ];
}

Or simply embed the relevant lines into your existing configuration (e.g. within configuration.nix).

• Rebuild to install wg and wg-quick commands and reboot to apply firewall changes
• Generate a private and public key for wireguard

NOTE: umask will invert the bits given for any new files, in this case it will make the privatekey and publickey files be marked with 700, or read/write/execute for current user, and no access for group or global.

mkdir ~/wireguardtemp
cd ~/wireguardtemp
umask 077
wg genkey | tee privatekey | wg pubkey > publickey

• Create a wireguard config

You can name this whatever you like, for example: home_network.conf. wg0 is also a commonly chosen name.

Remove all < and >, they are to indicate values you provide.

cd ~/wireguardtemp
nano ./home_network.conf

[Interface]
PrivateKey = <client private key>
Address = <client wireguard ip>/32
DNS = <internal dns address for wireguard network>

[Peer]
PublicKey = <server public key>
Endpoint = <server public ip>:13231
AllowedIPs = 0.0.0.0/0

NOTE: You can replace AllowedIPs = 0.0.0.0/0 with specific ranges to route only traffic destined for your internal network. For example AllowedIPs = 192.168.0.0/16, 10.0.0.0/8

• On your wireguard server, create a new peer using the client public key that you generated, ensuring that the allowed address on the server matches what’s set in the .conf file
• Test the configuration with wg-quick to ensure it’s working

cd ~/wireguardtemp
wg-quick up ./home_network.conf

If this doesn’t work, try searching for solutions using wg-quick as a key term.

Assuming you’ve got it working, spin down the connection with:

cd ~/wireguardtemp
wg-quick down ./home_network.conf

• Import the configuration into NetworkManager

NOTE: Using the GUI to import the file DOES NOT WORK at the time of writing. You MUST use nmcli to add the file.

cd ~/wireguardtemp
nmcli con import type wireguard file ./home_network.conf
nmcli connection modify home_network autoconnect no
nmcli connection down home_network

• (optional) Give the vpn network a pretty name

nmcli connection modify home_network con-name "Home Network"

• (optional) Save the private key and/or .conf file to your password manager of choice (e.g. 1Password or VaultWarden)
• Remove the temp files (privatekey, publickey, and home_network.conf)

rm -rf ~/wireguardtemp

• Theoretically, you should be set! You can now enable or disable the wireguard connection through the vpn option in network manager (available in the system menu on the top right).
